E.6

SEL-311C Relay Instruction Manual Date Code 20060320

Compressed ASCII Commands

CSTATUS Command—SEL-311C

Display status data in Compressed ASCII format by sending:

CST <CR>

The relay sends:

"Relay FID string","yyyy"<CR>

"MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","yyyy"<CR>

xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>

"IA","IB","IC","IP","VA","VB","VC","VS","MOF","+5V_PS","+5V_REG",

"-5V_REG","+12V_PS","-12V_PS","+15V_PS","-15V_PS",

"TEMP","RAM","ROM","A/D","CR_RAM","EEPROM","IO_BRD","yyyy"<CR>

,"xxxx","xxxx","xxxx","xxxx","xxxx","xxxx",

"xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx",

"xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","xxxx","yyyy"<CR><ETX>

where:

"xxxx" = the data values corresponding to the first line labels.

"yyyy" = the 4-byte hex ASCII representation of the checksum.
