Schweitzer Engineering Laboratories SEL-311C - Table 7.11 Mnemonic Settings for Metering on the Rotating Default Display

7.44
SEL-311C Relay Instruction Manual Date Code 20060320
Inputs, Outputs, Timers, and Other Control Logic
Rotating Default Display (Only on Models With LCD)
Table 7.11 Mnemonic Settings for Metering on the Rotating Default Display (Sheet 1 of 3)
Mnemonic Display Description
IA I A = x. xxxA yyy°IA input current
IB I B = x. xxxA yyy°IB input current
IC I C = x. xxxA yyy°IC input current
IP I P = x. xxxA yyy°IN input current
VA V A = x . x x x K V y y y ° VA input voltage
VB V B = x . x x x K V y y y ° VB input voltage
VC V C = x . x x x K V y y y ° VC input voltage
VS V S = x . x x x K V y y y ° VS input voltage
IG I G = x. xxxA yyy°IG = IA + IB +IC (residual)
3IO 3 I O = x. xxxA yyy°3IO = IG (zero-sequence)
I1 I 1 = x. xxxA yyy°positive-sequence current
3I2 3 I 2 = x . x x x A y y y ° negative-sequence current
3V0 3 V 0=x. xxxKV yyy°zero-sequence current
V1 V 1 = x . x x x K V y y y ° positive-sequence voltage
V2 V 2 = x . x x x K V y y y ° negative-sequence voltage
MWA M W A = x x . x x x A megawatts
MWA M W B= xx. xxxB megawatts
MWC M W C= xx. xxxC megawatts
MW3 M W 3 P = x x . x x x three-phase megawatts
MVARA M V A R A = x x . x x x A megavars
MVARB M V A R B = x x . x x x B megavars
MVARC M V A R C = x x . x x x C megavars
MVAR3 M V A R 3 P = x x . x x x three-phase megavars
PFA P F A = x . x x L E A D A power factor
PFB P F B = x . x x L A G B power factor
PFC P F C = x . x x L A G C power factor
PF3 P F 3 P = x . x x L E A D three-phase power factor
FREQ F R Q = x x . x system frequency from VA
VDC V D C = x x x . x v DC voltage
IADEM I A D E M = x . x x x IA demand current
IAPK I A P E A K = x . x x x IA peak current
IBDEM I B D E M = x . x x x IB demand current
IBPK I B P E A K = x . x x x IB peak current
ICDEM I C D E M = x . x x x IC demand current
ICPK I C P E A K = x . x x x IC peak current
IPDEM I P D E M = x . x x x IP demand current
IPPK I PPEAK = x. xxxIP peak current
3I2DEM 3 I 2 D E M = x . x x x 3I2 demand current
3I2PK 3 I 2 P E A K = x . x x x 3I2 peak current
MWADI M W A I N D E M = x . x x x A demand megawatts in
MWAPI M W A I N P K = x . x x x A peak megawatts in
