Schweitzer Engineering Laboratories SEL-311C - Table 12.5 Communication Elements Event Report Columns

12.15
Date Code 20060320 Instruction Manual SEL-311C Relay
Standard Event Reports and SER
Standard 15/30/60/180-Cycle Event Reports
Out2 1 2
c
OUT205
e
, OUT206
e
1
2
b
Output contact OUT211 asserted.
Output contact OUT212 asserted.
Both OUT211 and OUT212 asserted.
In1 1 2 IN101
d
, IN102
d
1
2
b
Optoisolated input IN101 asserted.
Optoisolated input IN102 asserted.
Both IN101 and IN102 asserted.
In1 3 4 IN103
d
, IN104
d
3
4
b
Optoisolated input IN103 asserted.
Optoisolated input IN104 asserted.
Both IN103 and IN104 asserted.
In1 5 6 IN105
d
, IN106
d
5
6
b
Optoisolated input IN105 asserted.
Optoisolated input IN106 asserted.
Both IN105 and IN106 asserted.
In2 1 2 IN201
e
, IN202
e
1
2
b
Optoisolated input IN201 asserted.
Optoisolated input IN202 asserted.
Both IN201 and IN202 asserted.
In2 3 4 IN203
e
, IN204
e
3
4
b
Optoisolated input IN203 asserted.
Optoisolated input IN204 asserted.
Both IN203 and IN204 asserted.
In2 5 6 IN205
e
, IN206
e
5
6
b
Optoisolated input IN205 asserted.
Optoisolated input IN206 asserted.
Both IN205 and IN206 asserted.
In2 7 8 IN207
e
, IN208
e
7
8
b
Optoisolated input IN207 asserted.
Optoisolated input IN208 asserted.
Both IN207 and IN208 asserted.
a
This column is visible only when positive-sequence, polarized phase mho elements are enabled (E21P does not contain "C").
b
This column is visible only when compensator distance mho elements are enabled (E21P contains "C").
c
Output contacts can be A or B type contacts (see Ta bl e 2 .2 and Figure 7.27 and Figure 7.28).
d
Models 311C00x and 311C01x.
e
Model 311C01x.
Table 12.5 Communication Elements Event Report Columns (Sheet 1 of 4)
Column
Heading
Corresponding
Elements
(Relay Word Bits)
Symbol Definition
3PO 3PO * Three pole open condition 3PO asserted.
SOTF SOTF * Switch-onto-fault condition SOTF asserted.
PT PT * Permissive trip signal to POTT logic PT asserted.
PTRX PTRX1, PTRX2 1 Permissive trip 1 signal from DCUB logic PTRX1 asserted.
2 Permissive trip 2 signal from DCUB logic PTRX2 asserted.
b Both PTRX1 and PTRX2 asserted
Z3RB Z3RB * Zone /Level 3 reverse block Z3RB asserted.
KEY KEY * Key permissive trip signal KEY asserted.
EKEY EKEY * Echo key EKEY asserted.
ECTT ECTT * Echo conversion to trip condition ECTT asserted.
WFC WFC * Weak-infeed condition WFC asserted.
Table 12.4 Output, Input, Protection, and Control Element Event Report Columns (Sheet 6 of 6)
Column Heading
Corresponding
Elements (Relay
Word Bits)
Symbol Definition
