G.7

Date Code 20060320 Instruction Manual SEL-311C Relay

SEL Synchrophasors

Protocol Operation

Table G.4 Permissible Message Periods Requested by Enable Message

Message Period (Hex)

Fast Messages Sent This

Number of Seconds After

the Top of Each Minute

Number of Fast

Messages per Minute

0064h 0,1,2,3,4,5,…,59 60

00C8h 0,2,4,6,8,10,…,58 30

012Ch 0,3,6,9,12,15,…,57 20

0190h 0,4,8,12,15,…,56 15

01F4h 0,5,10,15,20,…,55 12

0258h 0,6,12,18,24,…,54 10

03E8h 0,10,20,30,40,50 6

05DCh 0,15,30,45 4

07D0h 0,20,40 3

0BB8h 0,30 2

1770h 0 1
