9.16
SEL-311C Relay Instruction Manual Date Code 20060320
Setting the Relay
Relay Word Bits (Used in SEL
OGIC Control Equations)
Relay Word Bits (Used in SELOGIC Control Equations)
Relay Word bits are used in SELOGIC control equation settings. Numerous
SEL
OGIC control equation settings examples are given in Section 3–Section 8.
SEL
OGIC control equation settings can also be set directly to 1 (logical 1) or 0
(logical 0). Appendix H: Setting SEL
OGIC Control Equations gives SELOGIC
control equation details, examples, and limitations.
The Relay Word bit row numbers correspond to the row numbers used in the
TAR command (see TAR Command (Display Relay Element Status) on
page 10.31). Rows 0 and 1 are reserved for the display of the two front-panel
target LED rows.
Table 9.5 SEL-311C Models 0311C00x and 0311C01x Relay Word Bits (Sheet 1 of 2)
Row Relay Word Bits
0
EN TRP TIME COMM SOTF RCRS RCLO 51
1
A B C G ZONE1 ZONE2 ZONE3 ZONE4
2
M1P M1PT Z1G Z1GT M2P M2PT Z2G Z2GT
3
Z1T Z2T 50P1 67P1 67P1T 50G1 67G1 67G1T
4
51G 51GT 51GR LOP ILOP ZLOAD ZLOUT ZLIN
5
LB1 LB2 LB3 LB4 LB5 LB6 LB7 LB8
6
LB9 LB10LB11LB12LB13LB14LB15LB16
7
RB1 RB2 RB3 RB4 RB5 RB6 RB7 RB8
8
RB9 RB10 RB11 RB12 RB13 RB14 RB15 RB16
9
LT1 LT2 LT3 LT4 LT5 LT6 LT7 LT8
10
LT9 LT10 LT11 LT12 LT13 LT14 LT15 LT16
11
SV1 SV2 SV3 SV4 SV1T SV2T SV3T SV4T
12
SV5 SV6 SV7 SV8 SV5T SV6T SV7T SV8T
13
SV9 SV10 SV11 SV12 SV9T SV10T SV11T SV12T
14
SV13 SV14 SV15 SV16 SV13T SV14T SV15T SV16T
15
MAB1 MBC1 MCA1 MAB2 MBC2 MCA2 CVTBL SOTFT
16
MAG1 MBG1 MCG1 MAG2 MBG2 MCG2 DCHI DCLO
17
BCW BCWA BCWB BCWC FIDEN FSA FSB FSC
18
SG1 SG2 SG3 SG4 SG5 SG6 OC CC
19
CLOSE CF TRGTR 52A 3PO SOTFE VPOLV 50L
20
PDEM GDEM QDEM TRIP 50QF 50QR 50GF 50GR
21
32QF 32QR 32GF 32GR 32VE 32QGE 32IE 32QE
22
F32I R32I F32Q R32Q F32QG R32QG F32V R32V
23
* * IN106 IN105 IN104 IN103 IN102 IN101
a
24
ALARM OUT107 OUT106 OUT105 OUT104 OUT103 OUT102 OUT101
b
25
M3P M3PT Z3G Z3GT M4P M4PT Z4G Z4GT
26
Z3T Z4T 50P2 67P2 67P2T 50P3 67P3 67P3T
27
50G2 67G2 67G2T 50G3 67G3 67G3T * *
28
51P 51PT 51PR Z1X 59VA MAB3 MBC3 MCA3
29
MAG3 MBG3 MCG3 27S 59S * 59VP 59VS
