Schweitzer Engineering Laboratories SEL-311C - Functions Unique to the Front-Panel Interface; Reclosing Relay Shot Counter Screen

11.6
SEL-311C Relay Instruction Manual Date Code 20060320
Front-Panel Interface (Only on Models With LCD)
Functions Unique to the Front-Panel Interface
Functions Unique to the Front-Panel Interface
Three front-panel primary functions do not have serial port command
equivalents. These are:
➤ Reclosing relay shot counter screen (accessed via the {OTHER}
pushbutton)
➤ Local control (accessed via the {CNTRL} pushbutton)
➤ Modified rotating display with scroll lock control (accessed via
the {OTHER} pushbutton)
Reclosing Relay Shot
Counter Screen
Use this screen to see the progression of the shot counter during reclosing
relay testing.
Access the reclosing relay shot counter screen via the {OTHER} pushbutton. The
following screen appears:
Scroll right with the right arrow button and select function
79. Upon selecting
function
79, the following screen appears (shown here with demonstration
settings):
or
If the reclosing functions are disabled (see Reclosing Relay on page 6.11), the
following screen appears:
The corresponding text label settings (shown with example settings) are:
79LL = SET RECLOSURES (Last Shot Label—limited to 14 characters)
79SL = RECLOSE COUNT (Shot Counter Label—limited to 14 characters)
DATE TIME 79
TAR BRK_MON LCD
SET RECLOSURES=2
RECLOSE COUNT =0
SET RECLOSURES=2
RECLOSE COUNT =2
No Reclosing set
