SEL-311C Relay Instruction Manual Date Code 20060320
DNP Communications
DNP3 Documentation
Data Map
Each version of the SEL-311C has a slightly different data map. The following
is the default object map supported by the SEL-311C wye-connected PTs
(FID = SEL-311C-Rxxx-VM-Dxxxxxxxx).
60 3 Class 2 Data 1,20,21 6,7,8
60 4 Class 3 Data 1,20,21 6,7,8
70 1 File Identifier
80 1 Internal Indications 2 0,1 index = 7
81 1 Storage Object
82 1 Device Profile
83 1 Private Registration Object
83 2 Private Registration Object Descriptor
90 1 Application Identifier
100 1 Short Floating Point
100 2 Long Floating Point
100 3 Extended Floating Point
101 1 Small Packed Binary—Coded Decimal
101 2 Medium Packed Binary—Coded Decimal
101 3 Large Packed Binary—Coded Decimal
No object 13,14,23
a
Default
Table I.4 SEL-311C Relay DNP Object Table (Sheet 4 of 4)
Object Request (supported) Response (may generate)
Obj. Var. Description
Function
Codes
(decimal)
Qualifier
Codes (hex)
Function
Codes
(decimal)
Qualifier Codes
(hex)
Ta ble I . 5 S EL -31 1C-Wye D NP Da ta M ap (Sheet 1 of 3)
DNP
Object Type
Index Description
01,02 000–499 Relay Word, where 51 is 0 and 81D1T is 431.
01,02 500–999 Relay Word from the SER,
encoded same as inputs 000–499 with 500 added.
01,02 1000–1015 Relay front-panel targets, where 1015 is A,
1008 is ZONE4, 1007 is EN and 1000 is 51.
01,02 1016–1019 Power factor leading for A-, B-, C-, and 3-phase.
01,02 1020 Relay Disabled.
01,02 1021 Relay diagnostic failure.
01,02 1022 Relay diagnostic warning.
01,02 1023 New relay event available.
01,02 1024 Settings change or relay restart.
10,12 00–15 Remote bits RB1–RB16
10,12 16 Pulse Open command OC.
10,12 17 Pulse Close command CC.
10,12 18 Reset demands.
