Date Code 20060320 Instruction Manual SEL-311C Relay
Serial Port Communications and Commands
Command Explanations
=>HIS <Enter>
SEL-311C POTT Date: 10/12/99 Time: 16:24:01.623
EXAMPLE: BUS B, BREAKER 3
# DATE TIME EVENT LOCAT CURR FREQ GRP SHOT TARGETS
1 10/01/99 08:33:00.365 TRIG $$$$$$$ 1 60.00 3 2
2 10/02/99 20:32:58.361 ER $$$$$$$ 231 60.00 2 2
3 10/03/99 07:30:11.055 AG T 9.65 2279 60.00 3 2 TIME 51
=>
The fault locator has influence over information in the EVENT and LOCAT
columns. If the fault locator is enabled (enable setting EFLOC = Y), the fault
locator will attempt to run if the event report is generated by a trip (assertion
of TRIP Relay Word bit) or other programmable event report trigger condition
(SEL
OGIC
®
control equation setting ER).
If the fault locator runs successfully, the location is listed in the
LOCAT column,
and the event type is listed in the
EVENT column:
If a trip occurs in the same event report, a “T” is appended to the event type
(e.g., AG T).
If the fault locator is disabled or does not run successfully,
$$$$$$$ is listed in
the
LOCAT column. For either of these cases where the fault locator does not
run, the event type listed in the
EVENT column is one of the following:
The
TARGETS column will display any of the following illuminated front-panel
target LEDs if the event report is generated by a trip (assertion of TRIP Relay
Word bit):
TIME COMM SOTF 51 Zone 1 Zone 2 Zone 3 Zone 4
Table 10.6 Event Types
Event Type Faulted Ph ase
AG
A-phase to ground
BG
B-phase to ground
CG
C-phase to ground
AB
A-B phase-to-phase
BC
B-C phase-to-phase
CA
C-A phase-to-phase
ABG
A-B phase-to-phase to ground
BCG
B-C phase-to-phase to ground
CAG
C-A phase-to-phase to ground
ABC
three-phase
Event Type Description
TRIP event report generated by assertion of Relay Word bit TRIP
ER event report generated by assertion of
SEL
OGIC control equation event report trigger setting ER
PULSE event report generated by execution of the PUL (Pulse) command
TRIG event report generated by execution of the TRI (Trigger) command
