SEL-311C Relay Command Summary
Access Level 0
Command
The only thing that can be done at Access Level 0 is to go to Access Level 1. The screen
prompt is: =
ACC Enter Access Level 1. If the main board password jumper is not in place, the relay prompts for entry of
the Access Level 1 password in order to enter Access Level 1.
Access Level 1
Commands
The Access Level 1 commands primarily allow the user to look at information (e.g., settings,
metering), not change it. The screen prompt is: =>
2AC Enter Access Level 2. If the main board password jumper is not in place, the relay prompts for entry of
the Access Level 2 password in order to enter Access Level 2.
BAC Enter Breaker Access Level (Access Level B). If the main board password jumper is not in place, the
relay prompts for entry of the Access Level B password.
BRE Display breaker monitor data (trips, interrupted current, wear).
CAS Display compressed ASCII configuration data.
CEV [n Sx Ly L R C P] Display compressed event report (parameters in [ ] are optional)
where: n event number (1–43 if LER = 15; 1–25 if LER = 30; 1–13 if LER = 60; 1–4 if LER = 180;
defaults to 1).
Sx x samples per cycle (4 or 16); defaults to 4. If Sx parameter is present, it overrides the L parameter.
Ly y cycles event report length (1–LER) for filtered event reports, (1–LER + 1) for raw event reports,
defaults to LER if not specified.
L 16 samples per cycle; overridden by the Sx parameter, if present.
R specifies raw (unfiltered) data; defaults to 16 samples per cycle unless overridden by the
Sx parameter. Defaults to LER + 1 cycles in length unless overridden with the Ly parameter.
C specifies 16 samples per cycle, LER-cycle length.
P precise to synchrophasor-level accuracy.
CHIS Display compressed history.
COM p L Show a long format communications summary report for all events on M
IRRORED BITS
®
Channel p.
COM p n Show a communications summary for latest n events on M
IRRORED BITS Channel p.
COM p m n Show a communications summary report for events n through m on M
IRRORED BITS Channel p.
COM p d1 Show a communications summary report for events occurring on date d1 on M
IRRORED BITS Channel p.
COM p d1 d2 Show a communications summary report for events occurring between dates d1 and d2 on M
IRRORED
B
ITS Channel p. Entry of dates is dependent on the Date Format setting DATE_F (= MDY or YMD).
COM C p Clears the communications summary report for Channel p.
CST Display compressed status report.
CSU Display compressed event summary.
DAT Show date.
DAT m/d/y Enter date in this manner if Date Format setting DATE_F = MDY.
DAT y/m/d Enter date in this manner if Date Format setting DATE_F = YMD.
DNP [type] Show DNP map.
EVE n Show event report number n with 1/4-cycle resolution.
EVE L n Show event report number n with 1/16-cycle resolution.
EVE R n Show raw event report number n with 1/16-cycle resolution.
