SEL-311C Relay Instruction Manual Date Code 20060320
SEL-311C Relay Command Summary
Access Level 1
Commands
The Access Level 1 commands primarily allow the user to look at information (e.g., settings,
metering), not change it. The screen prompt is: =>
EVE C n Show compressed event report number n for use with SEL-5601 Analytic Assistant.
EVE P n Show event report n with synchrophasor-level accuracy time alignment.
GRO Display active group number.
HIS n Show brief summary of the n latest event reports.
HIS C Clear the brief summary and corresponding event reports.
ID Display relay identification and configuration information.
INI Displays input/output contact information.
INI T Displays I/O contact information and I/O board type.
IRI Force synchronization attempt of internal relay clock to IRIG-B time-code input.
MET k Display instantaneous metering data. Enter k for repeat count.
MET D Display demand and peak demand data. Enter MET RD or MET RP to reset.
MET E Display energy metering data. Enter MET RE to reset.
MET M Display maximum/minimum metering data. Enter MET RM to reset.
MET PM [time] [k] Display synchrophasor measurements (available when TSOK = logical 1). Enter time to display the
synchrophasor for an exact specified time, in 24-hour format. Enter k for repeat count.
QUI Quit. Returns to Access Level 0. Terminates SEL Distributed Port Switch Protocol (LMD) protocol
connection. Available in all access levels.
SER n Show the latest n rows in the Sequential Events Recorder (SER) event report.
SER m n Show rows m through n in the Sequential Events Recorder (SER) event report.
SER d1 Show rows in the Sequential Events Recorder (SER) event report from date d1.
SER d1 d2 Show rows in the Sequential Events Recorder (SER) event report from date d1 to d2. Entry of dates is
dependent on the Date Format setting DATE_F (= MDY or YMD).
SER C Clears the Sequential Events Recorder (SER).
SHO n Show relay settings (overcurrent, reclosing, timers, etc.) for Group n.
SHO L n Show SEL
OGIC
®
control equation settings for Group n.
SHO G Show global settings.
SHO P n Show Port n settings.
SHO R Show Sequential Events Recorder (SER) settings.
SHO T Show text label settings.
STA Show relay self-test status.
SUM Show newest event summary.
SUM A Acknowledge oldest event summary.
SUM N View oldest unacknowledged event report.
SUM N [A] Display or acknowledge event summary number “N.”
TAR R Reset the front-panel tripping targets.
TAR n k Display Relay Word row. If n = 0 through 53, display row n. If n is an element name (e.g., 50G1) dis-
play the row containing element n. Enter k for repeat count.
TIM Show or set time (24-hour time). Show time presently in the relay by entering just TIM. Example time
22:47:36 is entered with command TIM 22:47:36.
TRI [time] Trigger an event report. Enter time to trigger an event at an exact specified time, in 24-hour format.
