Date Code 20060320 Instruction Manual SEL-311C Relay
Application Settings for SEL-221 Series Relays
SEL-221F to SEL-311C Settings Conversion Guide
SELOGIC Variables Equations
SV1 = 25A1
SV2 = 59VP * !59VS * !50L * LT1 + 59VS * !59VP * !50L * LT2
SV3 = M3P + Z3G
SV4 = 0
SELOGIC Latch Equations
The SELOGIC latch equations emulate the SEL-221F setting PSVC for
settings P, S, and E.
The following contact input assignments are made automatically by the
SEL-311C when setting APP = 221F. These assignments cannot be changed
unless setting APP is changed back to APP = 311C.
Default Contact Input Functions
IN101 = Programmable Input (Direct Trip)
IN102 = PT (Permit trip)
IN103 = BT (Block trip)
IN104 = CL (Close breaker)
IN105 = 52A
IN106 = EXT (External event report trigger)
Table 14.17 SEL-221F Setting PSVC for Settings P, S, and E
SEL-311C
Relay Word Bit
PSVC = S
(Default)
PSVC = P PSVC = E
SET1= 0= 1= 1
RST1= 1= 0= 0
SET2= 1= 0= 1
RST2= 0= 1= 0
