Date Code 20060320 Instruction Manual SEL-311C Relay
Application Settings for SEL-221 Series Relays
SEL-2PG10 to SEL-311C Settings Conversion Guide
Default Tripping Logic Equations
TR = MABC1 + MPP1 + 51GT + 67G1T + OC
SELOGIC Torque Control Equations
51GTC = M2P (Setting 51NTC = 1)
SELOGIC Variables Equations
SV1 = 0 (Reserved for non-directional instantaneous overcurrent timer)
Default Contact Input Functions
Default Output Contact Logic Equations
OUT101 = TRIP
OUT102 = TRIP
OUT103 = MABC1 (Reserved for A1)
OUT104 = MPP1 (Reserved for A2)
OUT105 = 51G (Reserved for A3)
OUT106 = 51GT (Reserved for A4)
OUT107 = 67G1T (Reserved for A5)
Table 14.35 Default SEL-2PG10 Mask Logic Setting for MT
50L ZABC ZP ZPT 67NP 67NT 67NI 67DT
01100110
SEL-311C Input
IN101 IN102 IN103 IN104 IN105 IN106
SEL-2PG10 Label
ET1 ET2 E1 E2 E3 52A
Function
External
Trigger 1
External
Trigger 2
Monitor 1 Monitor 2 Monitor 3 Circuit breaker
auxiliary contact
