I.11
Date Code 20060320 Instruction Manual SEL-311C Relay
DNP Communications
DNP3 Documentation
10,12 19 Reset demand peaks.
10,12 20 Reset energies.
10,12 21 Reset breaker monitor.
10,12 22 Reset front-panel targets.
10,12 23 Read next relay event.
10,12 24–31 Remote bit pairs RB1–RB16.
10,12 32 Open/Close pair OC & CC.
20,22 00 Active settings group.
20,22 01 Internal breaker trips.
20,22 02 External breaker trips.
30,32 00,01 IA magnitude and angle.
30,32 02,03 IB magnitude and angle.
30,32 04,05 IC magnitude and angle.
30,32 06,07 IP magnitude and angle.
30,32 08,09 VA magnitude (kV) and angle.
30,32 10,11 VB magnitude (kV) and angle.
30,32 12,13 VC magnitude (kV) and angle.
30,32 14,15 VS magnitude (kV) and angle.
30,32 16,17 IG magnitude and angle.
30,32 18,19 I1 magnitude and angle.
30,32 20,21 3I2 magnitude and angle.
30,32 22,23 3V0 magnitude (kV) and angle.
30,32 24,25 V1 magnitude (kV) and angle.
30,32 26,27 V2 magnitude (kV) and angle.
30,32 28–31 MW A-, B-, C-, and 3-phase.
30,32 32–35 MVAR A-, B-, C-, and 3-phase.
30,32 36–39 Power factor A-, B-, C-, and 3-phase.
30,32 40 Frequency.
30,32 41 VDC.
30,32 42, 43 A-phase MWhr in and out.
30,32 44, 45 B-phase MWhr in and out.
30,32 46, 47 C-phase MWhr in and out.
30,32 48, 49 3-phase MWhr in and out.
30,32 50, 51 A-phase MVARhr in and out.
30,32 52, 53 B-phase MVARhr in and out.
30,32 54, 55 C-phase MVARhr in and out.
30,32 56, 57 3-phase MVARhr in and out.
30,32 58–62 Demand IA, IB, IC, IG, and 3I2 magnitudes.
Ta ble I . 5 S EL -31 1C-Wye D NP Da ta M ap (Sheet 2 of 3)
DNP
Object Type
Index Description
