D.4
SEL-311C Relay Instruction Manual Date Code 20060320
Configuration, Fast Meter, and Fast Operate Commands
Message Definitions
0004 Analog channel offset
0054 Time stamp offset
005C Digital offset
494100000000 Analog channel name (IA)
01 Analog channel type (float)
FF Scale factor type
0000 Scale factor offset in Fast Meter message (HEX)
494200000000 Analog channel name (IB)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
494300000000 Analog channel name (IC)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
495000000000 Analog channel name (IP)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
564100000000 Analog channel name (VA)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
564200000000 Analog channel name (VB)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
564300000000 Analog channel name (VC)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
565300000000 Analog channel name (VS)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
465245510000 Analog channel name (FREQ)
01 Analog channel type
FF Scale factor type
0000 Scale factor offset in Fast Meter message
564241540000 Analog channel name (VBAT)
01 Analog channel type
Table D.4 A5C1 Fast Meter Configuration Block (Sheet 2 of 3)
Data Description
