Schweitzer Engineering Laboratories SEL-311C - Page 314

9.20
SEL-311C Relay Instruction Manual Date Code 20060320
Setting the Relay
Relay Word Bits (Used in SEL
OGIC Control Equations)
8 RB9 Remote Bit 9 asserted (see Figure 7.10)
RB10 Remote Bit 10 asserted (see Figure 7.10)
RB11 Remote Bit 11 asserted (see Figure 7.10)
RB12 Remote Bit 12 asserted (see Figure 7.10)
RB13 Remote Bit 13 asserted (see Figure 7.10)
RB14 Remote Bit 14 asserted (see Figure 7.10)
RB15 Remote Bit 15 asserted (see Figure 7.10)
RB16 Remote Bit 16 asserted (see Figure 7.10)
9 LT1 Latch Bit 1 asserted (see Figure 7.12) Latched control—replacing
traditional latching relays
LT2 Latch Bit 2 asserted (see Figure 7.12)
LT3 Latch Bit 3 asserted (see Figure 7.12)
LT4 Latch Bit 4 asserted (see Figure 7.12)
LT5 Latch Bit 5 asserted (see Figure 7.12)
LT6 Latch Bit 6 asserted (see Figure 7.12)
LT7 Latch Bit 7 asserted (see Figure 7.12)
LT8 Latch Bit 8 asserted (see Figure 7.12)
10 LT9 Latch Bit 9 asserted (see Figure 7.12)
LT10 Latch Bit 10 asserted (see Figure 7.12)
LT11 Latch Bit 11 asserted (see Figure 7.12)
LT12 Latch Bit 12 asserted (see Figure 7.12)
LT13 Latch Bit 13 asserted (see Figure 7.12)
LT14 Latch Bit 14 asserted (see Figure 7.12)
LT15 Latch Bit 15 asserted (see Figure 7.12)
LT16 Latch Bit 16 asserted (see Figure 7.12)
11 SV1 SEL
OGIC control equation
variable timer input SV1 asserted (see Figure 7.24)
Testing, Seal-in functions, etc.
(see Figure 7.26)
SV2 SEL
OGIC control equation
variable timer input SV2 asserted (see Figure 7.24)
SV3 SEL
OGIC control equation
variable timer input SV3 asserted (see Figure 7.24)
SV4 SEL
OGIC control equation
variable timer input SV4 asserted (see Figure 7.24)
SV1T SEL
OGIC control equation
variable timer output SV1T asserted (see Figure 7.24)
Control
SV2T SEL
OGIC control equation
variable timer output SV2T asserted (see Figure 7.24)
SV3T SEL
OGIC control equation
variable timer output SV3T asserted (see Figure 7.24)
SV4T SEL
OGIC control equation
variable timer output SV4T asserted (see Figure 7.24)
Table 9.6 Relay Word Bit Definitions for the SEL-311C (Sheet 4 of 16)
Row Bit Definition Primary Application
