Schweitzer Engineering Laboratories SEL-311C - Page 345

Date _______________
Date Code 20060320 Instruction Manual SEL-311C Relay
SET.15 of 32Settings Sheets for the SEL-311C Relay
Relay Settings (Serial Port Command SET and Front Panel)
SV1 Dropout Time (0.00–999999.00 cycles in 0.25-cycle steps) SV1DO =
SV2 Pickup Time (0.00–999999.00 cycles in 0.25-cycle steps)
SV2PU =
SV2 Dropout Time (0.00–999999.00 cycles in 0.25-cycle steps)
SV2DO =
SV3 Pickup Time (0.00–999999.00 cycles in 0.25-cycle steps)
SV3PU =
SV3 Dropout Time (0.00–999999.00 cycles in 0.25-cycle steps)
SV3DO =
SV4 Pickup Time (0.00–999999.00 cycles in 0.25-cycle steps)
SV4PU =
SV4 Dropout Time (0.00–999999.00 cycles in 0.25-cycle steps)
SV4DO =
SV5 Pickup Time (0.00–999999.00 cycles in 0.25-cycle steps)
SV5PU =
SV5 Dropout Time (0.00–999999.00 cycles in 0.25-cycle steps)
SV5DO =
SV6 Pickup Time (0.00–999999.00 cycles in 0.25-cycle steps)
SV6PU =
SV6 Dropout Time (0.00–999999.00 cycles in 0.25-cycle steps)
SV6DO =
SV7 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV7PU =
SV7 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV7DO =
SV8 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV8PU =
SV8 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV8DO =
SV9 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV9PU =
SV9 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV9DO =
SV10 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV10PU =
SV10 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV10DO =
SV11 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV11PU =
SV11 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV11DO =
SV12 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV12PU =
SV12 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV12DO =
SV13 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV13PU =
SV13 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV13DO =
SV14 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV14PU =
SV14 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV14DO =
SV15 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV15PU =
SV15 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV15DO =
SV16 Pickup Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV16PU =
SV16 Dropout Time (0.00–16000.00 cycles in 0.25-cycle steps)
SV16DO =
