Schweitzer Engineering Laboratories SEL-311C - Page 353

Date _______________
Date Code 20060320 Instruction Manual SEL-311C Relay
SET.23 of 32Settings Sheets for the SEL-311C Relay
Global Settings (Serial Port Command SET G and Front Panel)
Input IN104 debounce time
(0.00–2.00 cycles in 0.25-cycle steps)
IN104D =
Input IN105 debounce time
(0.00–2.00 cycles in 0.25-cycle steps)
IN105D =
Input IN106 debounce time
(0.00–2.00 cycles in 0.25-cycle steps)
IN106D =
Optoisolated Input Timers for Models 0311C01x—Extra I/O Board (See
Figure 7.2)
Input IN201 debounce time
(0.00–2.00 cycles in 0.25-cycle steps)
IN201D =
Input IN202 debounce time
(0.00–2.00 cycles in 0.25-cycle steps)
IN202D =
Input IN203 debounce time
(0.00–2.00 cycles in 0.25-cycle steps)
IN203D =
Input IN204 debounce time
(0.00–2.00 cycles in 0.25-cycle steps)
IN204D =
Input IN205 debounce time
(0.00–2.00 cycles in 0.25-cycle steps)
IN205D =
Input IN206 debounce time
(0.00–2.00 cycles in 0.25-cycle steps)
IN206D =
Input IN207 debounce time
(0.00–2.00 cycles in 0.25-cycle steps)
IN207D =
Input IN208 debounce time
(0.00–2.00 cycles in 0.25-cycle steps)
IN208D =
Breaker Monitor Settings (See Breaker Monitor on page 8.2)
Breaker monitor enable (Y, N) EBMON =
(Make the following settings if preceding enable setting EBMON = Y.)
Close/Open set point 1—max. (0–65000 operations)
COSP1 =
Close/Open set point 2—mid. (0–65000 operations)
COSP2 =
Close/Open set point 3—min. (0–65000 operations)
COSP3 =
kA Interrupted set point 1—min.
(0.00–999.00 kA primary in 0.01 kA steps)
KASP1 =
kA Interrupted set point 2—mid.
(0.00–999.00 kA primary in 0.01 kA steps)
KASP2 =
kA Interrupted set point 3—max.
(0.00–999.00 kA primary in 0.01 kA steps)
KASP3 =
Synchronized Phasor Settings (see Appendix G: SEL Synchrophasors)
Synchronized Phasor Measurement (Y, N) EPMU =
