12.20
SEL-311C Relay Instruction Manual Date Code 20060320
Standard Event Reports and SER
Example Standard 15-Cycle Event Report
=>>EVE <Enter>
SEL-311C POTT Date: 10/14/99 Time: 08:53:34.926
EXAMPLE: BUS B, BREAKER 3
FID=SEL-311C-R100-V0-Z001001-D19991118 CID=B142
Currents (Amps Pri) Voltages (kV Pri) V1 FREQ Vdc
IA IB IC IP IG VA VB VC VS Mem
[1]
102 -200 98 0 0 67.4 -131.6 64.3 67.4 67.1 60.00 27
171 2 -176 0 -3 112.9 1.9 -115.0 113.2 113.2 60.00 27
-103 199 -99 -1 -3 -67.5 131.6 -64.2 -67.5 -67.2 60.00 27
-173 -3 174 0 -2 -112.9 -2.0 115.0 -113.2 -113.1 60.00 27
[2]
102 -200 97 0 -1 67.6 -131.6 64.1 67.6 67.3 60.00 27
171 2 -175 -1 -2 112.8 2.0 -115.1 113.1 113.1 60.00 27
-103 199 -98 0 -2 -67.7 131.6 -64.0 -67.7 -67.4 60.00 27
-172 -3 175 -1 0 -112.8 -2.1 115.1 -113.1 -113.0 60.00 27
[3]
102 -201 97 0 -2 67.8 -131.6 63.9 67.8 67.5 60.00 27
171 2 -176 -1 -3 112.7 2.2 -115.2 113.0 113.0 60.00 27
-104 200 -97 -1 -1 -67.9 131.6 -63.9 -67.9 -67.5 60.00 27
-172 -4 175 0 -1 -112.6 -2.4 115.2 -112.9 -112.9 60.00 27
[4]
103 -270 165 0 -2 68.0 -130.8 63.0 68.0 67.6 60.00 27
171 -686 576 -1 61 112.6 3.2 -114.7 112.9 112.7 60.00 27
-104 936 -867 -1 -35 -68.1 121.8 -55.0 -68.1 -67.7 60.01 27
-172 1661 -1653 0 -164 -112.5 0.9 108.8 -112.8 -111.2 60.01 27>
[5]
103 -1532 1499 0 70 68.2 -113.8 47.9 68.2 67.0 60.01 27
171 -1948 1976 -1 199 112.5 -5.6 -103.5 112.8 109.0 60.01 27
-104 1531 -1500 0 -73 -68.3 113.8 -47.8 -68.3 -65.7 60.01 27
-171 1945 -1975 0 -201 -112.4 5.5 103.5 -112.7 -107.3 60.01 27
[6]
104 -1533 1500 -1 71 68.4 -113.8 47.7 68.3 64.8 60.01 27*
170 -1945 1973 0 198 112.4 -5.4 -103.6 112.7 106.1 60.01 27
-105 1533 -1503 -1 -75 -68.4 113.8 -47.7 -68.4 -64.2 60.01 27
-172 1944 -1973 -1 -201 -112.4 5.3 103.6 -112.6 -105.1 60.01 27
[7]
104 -1536 1504 0 72 68.5 -113.8 47.5 68.5 63.7 60.01 27
171 -1944 1971 0 198 112.3 -5.3 -103.6 112.6 104.4 60.01 27
-105 1538 -1507 -1 -74 -68.6 113.8 -47.5 -68.6 -63.3 60.01 27
-171 1940 -1970 0 -201 -112.2 5.1 103.7 -112.5 -103.8 60.01 27
[8]
104 -1539 1506 -1 71 68.7 -113.8 47.4 68.7 63.1 60.01 27
170 -1941 1968 -1 197 112.2 -5.1 -103.7 112.4 103.4 60.01 27
-105 1540 -1509 -1 -74 -68.8 113.8 -47.3 -68.8 -63.0 60.01 27
-171 1939 -1968 0 -200 -112.1 5.0 103.7 -112.4 -103.0 60.01 27
[9]
104 -1543 1510 0 71 68.9 -113.8 47.2 68.9 62.9 60.01 27
170 -1938 1965 -1 197 112.0 -4.9 -103.8 112.3 102.7 60.01 27
-106 1543 -1513 -1 -76 -69.0 113.8 -47.2 -69.0 -62.8 60.01 27
-171 1936 -1964 0 -199 -112.0 4.8 103.8 -112.3 -102.5 60.01 27
[10]
105 -1546 1513 0 72 69.1 -113.9 47.1 69.1 62.8 60.01 27
158 -1803 1835 0 190 111.9 -4.4 -104.3 112.2 102.4 60.01 27
-105 1446 -1429 -1 -88 -69.2 119.6 -52.8 -69.2 -62.9 60.01 27
-73 827 -847 -1 -93 -111.9 0.1 110.4 -112.2 -103.1 60.01 27
[11]
51 -673 671 0 49 69.2 -128.5 60.4 69.2 63.7 60.01 27
-1 7 -8 0 -2 111.8 4.0 -116.0 112.1 105.0 60.01 27
-1 -1 0 -1 -2 -69.3 131.6 -62.3 -69.3 -65.1 60.01 27
0 -1 -1 0 -2 -111.8 -4.1 116.0 -112.1 -106.7 60.01 27
[12]
0 0 -1 0 -1 69.4 -131.6 62.2 69.4 66.2 60.01 27
-1 0 0 0 -1 111.7 4.2 -116.1 112.0 108.0 60.01 27
0 -1 0 -1 -1 -69.5 131.6 -62.2 -69.5 -67.0 60.01 27
0 -1 -1 0 -2 -111.7 -4.3 116.1 -111.9 -108.9 60.01 27
[13]
-1 0 0 0 -1 69.6 -131.6 62.1 69.6 67.6 60.01 27
-1 0 0 -1 -1 111.6 4.4 -116.2 111.9 109.6 60.01 27
0 -1 0 -1 -1 -69.7 131.6 -62.0 -69.7 -68.1 60.01 27
0 -1 0 0 -1 -111.5 -4.5 116.2 -111.8 -110.1 60.01 27
[14]
0 0 0 0 0 69.8 -131.6 61.9 69.8 68.5 60.01 27
-1 -1 -1 0 -3 111.4 4.6 -116.3 111.7 110.5 60.01 27
0 -1 0 0 -1 -69.9 131.6 -61.8 -69.9 -68.9 60.01 27
0 0 -1 -1 -1 -111.4 -4.7 116.3 -111.7 -110.8 60.01 27
[15]
-1 0 0 0 -1 70.0 -131.6 61.7 70.0 69.1 60.01 27
-1 0 0 0 -1 111.3 4.8 -116.4 111.6 110.9 60.01 27
0 -1 -1 -1 -2 -70.1 131.5 -61.6 -70.1 -69.3 60.01 27
0 -1 0 -1 -1 -111.3 -4.9 116.4 -111.6 -111.1 60.01 27
(Continued on next page)
see Figure 12.1
firmware identifier
firmware checksum identifier
see Figure 12.4 and Figure 12.5
for details on this one cycle of
Phase B (Channel IB) current.
one cycle of data
