I.8
SEL-311C Relay Instruction Manual Date Code 20060320
DNP Communications
DNP3 Documentation
21 5 32-Bit Frozen Counter With Time of
Freeze
21 6 16-Bit Frozen Counter With Time of
Freeze
21 7 32-Bit Frozen Delta Counter With Time of
Freeze
21 8 16-Bit Frozen Delta Counter With Time of
Freeze
21 9 32-Bit Frozen Counter Without Flag
21 10 16-Bit Frozen Counter Without Flag
21 11 32-Bit Frozen Delta Counter Without Flag
21 12 16-Bit Frozen Delta Counter Without Flag
22 0 Counter Change Event—All Variations 1 6,7,8
22 1 32-Bit Counter Change Event Without
Time
1 6,7,8 129 17,28
22 2
a
16-Bit Counter Change Event Without
Time
1 6,7,8 129,130 17,28
22 3 32-Bit Delta Counter Change Event With-
out Time
22 4 16-Bit Delta Counter Change Event With-
out Time
22 5 32-Bit Counter Change Event With Time 1 6,7,8 129 17,28
22 6 16-Bit Counter Change Event With Time 1 6,7,8 129 17,28
22 7 32-Bit Delta Counter Change Event With
Time
22 8 16-Bit Delta Counter Change Event With
Time
23 0 Frozen Counter Event—All Variations
23 1 32-Bit Frozen Counter Event Without Time
23 2 16-Bit Frozen Counter Event Without Time
23 3 32-Bit Frozen Delta Counter Event Without
Time
23 4 16-Bit Frozen Delta Counter Event Without
Time
23 5 32-Bit Frozen Counter Event With Time
23 6 16-Bit Frozen Counter Event With Time
23 7 32-Bit Frozen Delta Counter Event With
Time
23 8 16-Bit Frozen Delta Counter Event With
Time
30 0 Analog Input—All Variations 1 0,1,6,7,8
30 1 32-Bit Analog Input 1 0,1,6,7,8 129 0,1,7,8
30 2 16-Bit Analog Input 1 0,1,6,7,8 129 0,1,7,8
Table I.4 SEL-311C Relay DNP Object Table (Sheet 2 of 4)
Object Request (supported) Response (may generate)
Obj. Var. Description
Function
Codes
(decimal)
Qualifier
Codes (hex)
Function
Codes
(decimal)
Qualifier Codes
(hex)
