Introduction
This section of the SEL-2032 Communications Processor instruction manual
includes information and procedures to install the SEL-2032 safely and
effectively. Safe and effective installation of the SEL-2032 requires proper
mounting, connection, communications, and setup. This section concludes
with steps for performing an initial check of your SEL-2032 and configuring it
for data collection.
Jumper Settings
This subsection describes the hardware jumper selections available on the
SEL-2032, and the recommended procedures for making the jumper setting
changes.
Main Board
Jumpers
Set the main board jumpers to meet your requirements. See Ta ble 2 .1 for
jumper functions and positions. See Figure 2.4 for jumper locations on the
main board.
Table 2.1 Main Board Jumper Positions
Function Install Jumpers At:
Connect +5 Vdc to pin 1 on:
Port 3/ /Port 4
Port 11/ /Port 12
Port 14/ /Port 16 (factory setting = all off)
J11, Position A/ /J11, Position C
J11, Position B/ /J11, Position D
J20, Position B/ /J20, Position A
Alarm Contact Form JMP3
Form A
Form B (factory setting)
(20 AWG wire) A to Common
(20 AWG wire) B to Common
Port 15 IRIG-B Direction
Input
Output (factory setting)
JMP1 Position 2-3; JMP2 Position 2-3
JMP1 Position 1-2; JMP2 Position 1-2
Port F Baud Rate (This jumper is read on power-up.)
2,400 baud, RTS/CTS = N, XON/XOFF = Y
Selected by SET P settings (factory setting)
J17 A Installed
J17 A Removed
Password Disable
Password Enable (factory setting)
J17 B Installed
J17 B Removed
Unused J17 C
J17 D
