Settings
Automatic Message (SET A) Settings
H = 3Ah (reset value defined with RH3A)
I = 222 (reset value defined with RI222)
Equation 7.2
Table 7.3 Decode Element Definitions
Element Definition
r Repeat Count. Optional number of times to repeat the data type in the
expanded Decode Equation. Range is 1–2048. Repeat count data items
are stored as an array.
Type Data Type. The parser ignores all leading white space (space or tab char-
acters) for all data types except C. See Table 7. 4 for specific data types
and definitions.
Reset Values If parsing fails, the SEL-2032 stores the data type reset value into the
database. See Tab le 7 .4 for data type reset values. Also see User-Defined
Reset Values.
n Length. Optional maximum expected size of the ASCII string for the
data type. Range is 1–32767. If n is not specified, the value of n is based
on the data type specified. See Table 7. 4 for the default length of n.
Once a valid character is found, all valid characters are read and stored
until the specified length of characters is read or an invalid character is
found.
@ Non-Storage Element. The @ sign causes the data item to be parsed
according to the data type, but not stored in the database. In the example,
I, F@, the @ sign reserves space for an integer, but not for the floating-
point. The @ sign cannot be specified with the label option.
label Optional Label. This optional label is applied to the data type. Only one
label is allowed per data type. Data elements with a repeat count share the
same label. Labels are limited to 10 characters, and characters must be
(a–z, A–Z, 0–9 or the underscore character). A label cannot be specified
with the @ sign option. The labels MONTH, DAY, YEAR, HOUR, MIN,
SECONDS, SEC, and MSEC are reserved by the SEL-2032. You may,
however, use these labels if they are not in uppercase. For example, Min
is an acceptable label.
Table 7.4 Data Type Characteristics (Sheet 1 of 2)
Data
Types
Definitions Reset Values
Default Length
(if n not specified)
I Integer (0–9 and leading + or –) 8000h 5 valid
characters plus sign
F Floating Point (0–9, + or –, and
scientific notation)
7F800000h 10 valid characters
C ASCII String (all ASCII characters
including leading white space)
‘’ (empty string) 1 character
S ASCII String (all ASCII characters
excluding leading white space)
‘’ (empty string) 1 character
H ASCII Hexadecimal Number (0–9,
A–F, a–f)
8000h 4 valid characters
RIv User-defined reset value for I Data
Type, where v is the reset value.
Format the same as I Data Type.
DECODE = "F, H, I, RF3.55, RH3A, RI222, F, H, I"
