SeaDoo GTX Series 2022 User Manual

Section 05 ELECTRICA L SYSTEM
Subsection 02 (WIRING HARNESS AND CONNECTORS)
Install the protective heat shrink rubber tube on
the terminal. Heat the heat shrink rubber tube us-
ing the heat gun so that it grasps the wire and the
terminal.
NOTICE
Make sure that the protective heat
shrink rubber tube has been properly installed
and no part of wire is exposed.
219100963-012 121

SeaDoo GTX Series 2022 Specifications

General

Engine Type	Rotax 1630 ACE
Engine Displacement	1630 cc
Seating Capacity	3
Hull Material	Fiberglass
Fuel Capacity	70 L
Length	345.1 cm
Width	125.5 cm
Fuel Type	Unleaded gasoline
Hull Type	ST3 Hull
