SeaDoo GTX Series 2022 - Replacing Intercooler Attachments

Section 02 ENGINE
Subsection 05 (INTERCOOLER)
TIGHTENING TOR
QUE
Intercoo ler air hoses
clamp
4N•m ± 1N•m
(35 lbf•in ±9l
bf•in)
Intercooler water hoses
clamp
1.7N•m ± .2N•m
(15 lbf•in ±2
lbf•in)
Intercoo ler bleed hose
clamp
1.7N•m ± .2N•m
(15 lbf•in ±2
lbf•in)
REPLACING INTERCOOLER
ATTACHMENTS
Remove the i
ntercooler.
Drill the head of the rivets.
NOTICE
Drilling ri
vets too deep may lead to
hull damage
.
smr2016-020-008_a
Install the attachment with new rivets and new
locking tie if required.
219100963-008 59
