Section 07 BODY AND HULL
Subsection 01 (BODY)
7. Install mirror using adhesive tape at the back of
mirror.
8. Install mirror trim by reversing the removal pro-
cedure.
BUMPERS
Removing the Bumper
Front Bumper
219100893-032-711_a
1. Front bu
mper
2. retaining screw
1. Remove screws securing front bumper to body.
219100893-032-710_a
1. Front bumper
2. Retaining screw
3. Side bumper
2. Remove front bumper from vehicle.
Rear Bumper
All models excluding Fish PRO.
1. Remove protective caps retaining screws.
21910089
3-032-010_a
2. Remove both protective caps (one on each
side).
2191
00893-032-006_a
3. Pull the top of bumper to unclip it from body.
219100963-021 223
