Section 05 ELECTRICAL SYSTEM
Subsection 06 (INFORMATION CENTER)
MESSAGE DISPLA
Y INFORMATION
WATER TEMP SENSOR DEFECTIVE
Problem with water temperature sensor, not sending
water t empera
ture info.
IBR MODULE ERROR
iBR system malfunction
MAINTENANCE REQUIRED
Watercraft maintenance required
When a digital warning appears, it will show the warning for 6 seconds and then the warning will disap-
pear for 15 minutes. During the 15 minutes, only the indicator lamps will be activated.
TROUBLESHOOTING
DIAGNOSTIC TIPS
IMPORTANT: When solving a n electrical problem,
the first thing to do is to check the battery condi-
tion as well as its cables and connections.
Make sure th
e battery is fully charged or install a
power pack f
or any tests that involves a prolonged
"key ON" pe
riod. If battery voltage gets too low,
not only te
st results can be altered, but the v ehicle
electrica
l system may not operate normally.
Pay attention to ground wires. They could be-
come loose or corroded which causes them to
act as an additional load in a circuit, dropping
voltage and reducing current to components.
Some components may be grounded through
their outer casing and mounted hardware. This
should also be considered.
Electric
al Connectors
Pay particular attention to ensure that pins are not
out of their connectors, loose, or damaged. The
troubleshooting procedures may not cover prob-
lems resulting from one of these causes.
NOTICE
Ensure a
ll terminals are properly
crimped
on wires and connector housings are
properl
y fastened. When replacing any electric
or elect
ronic part(s), always check electrical
connect
ions. Make sure that they are clean,
corros
ion-free, tight and make good contact.
The vol
tage and current might be too weak to
go thro
ugh dirty or corroded connector pins
or term
inals.
MULTIF
UNCTION GAUGE
TROUBL
ESHOOTING
GAUGE FUNCTIONS INOPERATIVE OR
WORKING INTERMITTENTLY
1. Power supply or ground problem
-Check
power supply and ground circuits.
PROCEDURES
TESTING THE MULTIFUNCTION
GAUGE
Before beginning any troubleshooting, test or re-
pair, always check for fault codes.
1. Check for fault codes using BUDS2.
2. Record all
fault codes, then erase them.
3. Perform a complete shutdown of the electrical
system and reactivate it.
4. Check fault codes. If a previous fault codes
reappears, perform the required service ac-
tions.
Testi ng t
he Multifunction Gauge Using
BRP Diagnostic Software (BUDS2)
Connect vehicle to the latest applicable BRP Diag-
nostic Software version. Refer to
COMMUNICA-
TION TOOLS
subsection.
Select th
e Functions tab.
Click on the Execute WOW Test button.
All indications will come and stay ON so that you
can verify each indication.
NOTE: The
WOW Test only tests the gauge LEDs
and LCD.
It does not test the actual circuit func-
tions re
lated to each indication.
Testing the Multifunction Gauge Power
Input
If the multifunction gauge is inoperative, first
check for fault codes with BRP Diagnostic Soft-
ware, record all faults then erase them. Reacti-
vate the electrical system and recheck for faults.
If any fault code appears, perform service actions
required. Refer to
COMMUNICATION TOOLS
subsection.
1. Remove multifunction gauge. Refer to proce-
dure in this subsection.
2. Perfo
rm testing at multifunction gauge connec-
tor as
per following illustration and tables.
140 219101047-001
