Section 07 BODY AND HULL
Subsection 01 (BODY)
1
2
219100693-021-102a
1. Retainer
2. Front atta
ching point
3. The hood’s rear tabs must be properly inserted
under the attachment points.
219100693-021-101a
4. The ga
p between the hood and the deck must
not ex
ceed 2 mm (.08 in).
A
219
100693-021-103a
A. 2 mm (.08 in)
5. Tighten the side retaining screws to specifica-
tion.
TIGHTENING TOR
QUE
Screw
3.25 N•m ± 0.75 N•m
(29 lbf•in ±7l
bf•in)
STORAGE COMPARTMENT
COVER
219100893-032-001_a
Removing the Storage Compartment
Cover
1. Remove hood.
2. Remove hinge retaining screws.
219100893-032-701_a
3. Unscrew gas shock from its upper attachment.
218 219100963-021
