SeaDoo GTX Series 2022 User Manual

INTRODUCTION
Section 06 ENGINE
Subsection 01 (MAGNETO)
MAGNETO
Models
55
mmr2008-001
XXX0000
Model
Loctite 243
5 Nm
(44 lbfin)
1
NEW
Page heading
indicates section
and subsection.
Exploded view assists
you in identifying parts
and their related
positions.
TYPICAL PAGE
Illustration number
for publishing process.
Subsection title
Indicates applicable
models.
Document number for
publishing process.
Bold face number
is used to identify
a part referred to
the text.
Drop represents a
service product
to be applied.
Dotted box contains
parts applicable to a
specific model.
Page number
NEW indicates that the
part must be replaced
with a new one.
Pay attention to torque specifications.
Some of these are in lbf in instead of lbf ft.
Use appropriate torque wrench.
NOTICE
Typical_iso_2008_en
XII 219100963-002

SeaDoo GTX Series 2022 Specifications

General

Engine Type	Rotax 1630 ACE
Engine Displacement	1630 cc
Seating Capacity	3
Hull Material	Fiberglass
Fuel Capacity	70 L
Length	345.1 cm
Width	125.5 cm
Fuel Type	Unleaded gasoline
Hull Type	ST3 Hull
