SeaDoo GTX Series 2022 User Manual

Section 05 ELECTRICA L SYSTEM
Subsection 07 (ACCESSORIES)
219100963-016-002
SONAR CONNECTOR PIN-OUT
INPUT VOLTAGE TEST AT VEHICLE CONNECTOR
PROBE VOLTAGE
Pin 2 (Hot with
main relay on )
Pin 3
(Permanen
t
ground)
Battery vo
ltage
219100963-016-003
VEHICLE CONNECTOR PIN-OUT
Repair wiring and/or connectors as required.
For further information, troubleshooting and diag-
nostic, refer to the sonar m anufacturer.
219100963-016 147
