Section 06 STEERING AND PROPULSION
Subsection 02 (iBR, REVERSE AND VTS)
VTS TRIM RING AND NOZZLE
5 ± 1 N•m
(44 ± 9 lbf•in)
27 ± 1 N•m
(20 ± 1 lbf•ft)
27 ± 1 N•m
(20 ± 1 lbf•ft)
Loctite 271
Loctite 271
Loctite 271
5 ± 1 N•m
(44 ± 9 lbf•in)
Loctite 271
= Component must be replaced when removed.
NEW
219100893-029-103_a
166 219100963-018
