SeaDoo GTX Series 2022 User Manual

Section 07 BODY AND HULL
Subsection 01 (BODY)
219100893-032-735_a
Slightly pull storage compartment out.
Cut locking ties retaining the ventilation hoses to
the bin.
Finish pulling the storage compartment out.
NOTE: Do not remove the lower shock reinforce-
ment while pulling the storage compartment out.
219100
963-021-020
Installing the Storage Compartment
The installation is the reverse of the removal pro-
cedure. However, pay attention to the following.
Ensure the lower shock reinforcement is in place
before installing the storage compartment.
Storage Cover Alignment
Before aligning the cover, ensure the storage
compartment, latch bases, anchorages hooks,
ventilation adapter and storage cover a re installed
and secured.
1. Detach one side of the shock absorber.
NOTICE
Make sure anchorage hooks are
properly installed.
219100893-032-200
2. Position the inner rib of the compartment cover
evenly front and back on the seal.
2.1 Move the storage compartment front to
rear to position the rib.
2.2 Carefully, close and latch the cover.
2.3 Check gap between cover and body.
2.4 Open the cover and check if the rib mark is
evenly located front and back on the seal.
2.5 If the mark is not center on the seal or gap
is not equal, move the compartment at the
proper position.
1
219100893-032-201
STORAGE COMPARTMENT SEAL
219100963-021 231

SeaDoo GTX Series 2022 Specifications

General

Engine Type	Rotax 1630 ACE
Engine Displacement	1630 cc
Seating Capacity	3
Hull Material	Fiberglass
Fuel Capacity	70 L
Length	345.1 cm
Width	125.5 cm
Fuel Type	Unleaded gasoline
Hull Type	ST3 Hull
