Section 07 BODY AND HULL
Subsection 02 (HULL)
25 ± 1 N•m
(18 ± 1 lbf•ft)
NEW
27 ± 1 N•m
(20 ± 1 lbf•ft)
27 ± 1 N•m
(20 ± 1 lbf•ft)
9 ± 1 N•m
(80 ± 9 lbf•in)
11 ± 1 N•m
(97 ± 9 lbf•in)
8.5 ± 1 N•m
(75 ± 9 lbf•in)
27 ± 1 N•m
(20 ± 1 lbf•ft)
27 ± 1 N•m
(20 ± 1 lbf•ft)
NEW
NEW
9 ± 1 N•m
(80 ± 9 lbf•in)
9 ± 1 N•m
(80 ± 9 lbf•in)
NEW
NEW
NEW
= Component must be replaced when removed.
NEW
Loctite 567
(pipe sealant)
Loctite 271
219100893-033-102_a
238 219100893-033
