Section 07 BODY AND HULL
Subsection 02 (HULL)
2. Disconnect hoses from jet pump support.
21910089
3-033-005_a
INSIDE THE HULL
1. Exhaust water supply hose
2. Bailer ho
ses
3. Remove jet pump support retaining nuts and
washers.
219100893-033-006_b
FROM INSIDE THE HULL
4. Heat the jet pump support using a heat gun in
order to soften the sealant.
5. Pull jet pump support off the hull.
6. If applicable, note the alignment shims l ocation.
NOTICE
Alignment shims have to be rein-
stalled at the same location.
Cleaning the Jet Pump Support
1. Scrape off all excess sealant from jet pump sup-
port, ride plate, and hull.
2. Inspect pump support for cracks or other dam-
age.
3. Clean jet pump support and hull surface with
BRP HEAVY DUTY CLEANER (P/N 293 110 001) to
eliminate grease, dust, and sealant residue.
Installing the Jet Pump Support
1. Make sure sealant contact areas are clean and
dry.
2. Apply
LOCTITE 5900 (P/N 293 800 066) on the jet
pump support as shown (thick black line).
219100893-033-007_a
SEALAN
TAPPLICATION
242
