Section 07 BODY AND HULL
Subsection 02 (HULL)
3. Install eyelet and other parts using new elastic
stop nuts as per following illustration.
21910089
3-033-014_a
1. Stern eyelet
2. Small washer
3. Loctite
5150 (silicone sealant) here
4. Rubber washer
5. Large washer
6. Elastic
stop nut
4. Tighten nuts to the specified torque.
TIGHTENING TORQUE
Eyelet retaining nuts
14.5 N•m ± 1.5 N•m
(128 lbf•in ±13lbf•in)
