SeaDoo GTX Series 2022 User Manual

Section 08 TECHNICAL SPECIFICATIONS
Subsection 01 (VEHICLES)
PROPULSION
Coupling type Crowned splines, direct drive
Drive shaft
Deflection (max.) 0.5 mm (.02 in)
Minimum required water level for propulsion system
90 cm (3 ft) und
erneath the lo west
rear portion of hull
IBR AND VTS
Description
Intelligent Brake and Reverse
activated by a LH lever.
Electronically-c on trolled iBR gate
to provide brake, reverse, neutral
and forward position
Forward Approx. from + 6° to -3°
Neutral Approx. -55°
Braking Approx. -70°
Gate angle
(from horizontal line
of watercraf t)
Reverse Approx. -70°
VTS system
Electronically-controlled through
the VTS control button with 3
preset positions
VTS range angle
8° up, -3° down
Actuator
12 V, 75 A max. capacity. Reversible
PWM (pulse-width modulation) motor
WEIGHT AND LOADING CAPACITY
GTX 155
348 kg (768 lb)
GTX 230
365 kg (805 lb)
GTX LTD 230
380 kg (838 lb)
GTX LTD 3
00
385 kg (849 lb)
RXT 230 365 kg (805 lb)
Wake Pro 370 kg (815 lb)
RXT-X 3
00
376 kg (
828 lb)
Dry weight
FISH PRO 155
391 kg (860 lb)
Number of passenger (driver incl.) 3
Load l
imit (passenger(s) and luggages)
272 kg
(600 lb)
All models except
FISH P
RO 155
102.5L (27U.S. gal.)
Stora
ge capacity
FISH P
RO 155
102.5L (27U.S. gal.)
+
51 L (13.5 U.S. g al.) Cooler
DIMENSIONS
All models except
FISH PRO 155
345.1 cm (135.9 in)
Overall length
FISH PRO 155
373.4 cm (147 in)
219100963-023 251

SeaDoo GTX Series 2022 Specifications

General

Engine Type	Rotax 1630 ACE
Engine Displacement	1630 cc
Seating Capacity	3
Hull Material	Fiberglass
Fuel Capacity	70 L
Length	345.1 cm
Width	125.5 cm
Fuel Type	Unleaded gasoline
Hull Type	ST3 Hull
