SeaDoo GTX Series 2022 User Manual

Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 05 (DIAGNOSTIC AND FAULT CODES)
This mode allows the rider to return home which
would otherwise not be possible.
When this mode is active, LIMP HOME MODE
will be displayed in the information center.
Indicator Lights and Message Display Information
The fault indicators and messages displayed in the information center will inform you of a particular con-
dition or if an anomaly occurs.
Standard Gauge
FAULT
INDICATOR (ON)
MESSAGE DISP
LAY
DESCRIPTION
HIGH TEMPER ATURE
Engine or exh
aust system overheating
CHECK ENG INE
or LIMP
HOME MODE
Check engine (minor fault req. maint.) or
iBR system fault or
LIMP HOME MOD
E (major e ng. fault)
LOW or HIGH BATTERY
VOLTAGE
Low/high battery voltage
LOW OIL PRESSURE
Low engine oil pressure detected
iBR MODULE ERROR
iBR system f
ault
Gauge for X Models
FAULT INDICATOR
(ON)
MESSAGE DISPLAY DESCRIPTION
LOW or HIGH
BATTERY
VOLTAGE
Low/high battery v oltage
HIGH TEMPERATURE
Engine or exhaust system overheating
CHECK ENGI
NE or LIMP
HOME MODE
Check engi
ne (minor fault req. maint.) or
LIMP HOME MODE (major eng. fault)
LOW OIL PRESSURE
Low oil pressure
_
iBR s ystem fa ult
FAUL T MES
SAGES
RIGHT OR LEFT KEYPAD ERROR
Gauge con tro l button malfunction
LOW OIL PRESSURE
Engine low oil pressure detected
HIGH EXHA
UST TEMPERATURE
High exhaust temperature detected
HIGH TEMPERATURE
High engine temperature detected
CHECK ENGINE
Engine management system malfunction or
maintenance required
HIGH BATTERY VOLTAGE
High battery voltage detected
LOW BATTERY VOLTAGE
Low battery voltage detected
74 219100893-019

SeaDoo GTX Series 2022 Specifications

General

Engine Type	Rotax 1630 ACE
Engine Displacement	1630 cc
Seating Capacity	3
Hull Material	Fiberglass
Fuel Capacity	70 L
Length	345.1 cm
Width	125.5 cm
Fuel Type	Unleaded gasoline
Hull Type	ST3 Hull
