Shibaura ST330 - Cultivating Implement Installing Device; Three-Point Link; Name of Major Parts of Three-Point Link; Standards for Three-Point Link

235
1. Three-point link
1） Name of major parts of three-point link
623Y
2） Standards for three-point link
The hydraulic three-point link is of the 1 type in conformity with the international standard category.
Any implements with mounting part in conformity with this standard may be mounted.
624Y
3-11 Cultivating Implement Installing Device
Type A B
C
(Max.)
D
(Min.)
E
(Max.)
F
(Min.)
G H J
K
(Min.)
N
Category
1Type
19
19.5
44 76 69 44.5 22
22.4
35 40 or 52
683±1.5
0
-0.084
0
+0.21 0
-0.21 0
+0.33 0
-0.2
1. Top link
2. Lift rod
3. Lower link
4. Fixed hitch
5. Adjustable
lift rod
6. Stabilizer
