216
31） TRAILER SOCKET
The trailer socket is installed left side on the
rear axle housing. This socket is a standard
seven pin socket.
32） FUSE BLOCK FOR HEADLAMP
The fuse blocks for headlamps are located
near the headlamp in the engine cover.
The fuse blocks hold fuses that protect
individual headlamps circuit.
Headlight Fuse Block
Fuse Size Circuit protected
①
7.5 amp Headlight - Low Beam
②
7.5 amp Headlight - High Beam
593Y
594Y
