84
3. INSPECTION AND SERVICE
1） Bearing
Replace if excessive play, discoloration, unsmooth
rotation, noise, etc. are noticed.
2） Backlash of gear
Replace if the service limit is exceeded.
Backlash of gear（mm）
Standard assembling
Value
Service limit
0.04－0.16
0.6
3） Shifter fork and slide gear
Replace if the service limit is exceeded.
Clearance between shifter fork and slide gear (mm)
Standard assembling value Service limit
0.1－0.3
1.0
4） Oil seal and O-ring
Replace with new ones.
354Y
355Y
