21
(
3) HST CRUISE CONTROL ROD
① Adjust the length of the cruise control rod as same as
before disassembled length. If didn’t measure length,
adjust it as shown.
NOTE：
If necessary, adjust the neutral position by turn the shaft
of the centering spring.
(4) FRONT AXLE SUPPORT BOLT
Apply the thread sealant on the bolts thread when install
the front axle support and tighten to 117~148 N·m
(11.9~15.1 kgf·m).
(5) POWER STEERING PIPING
Power steering pipings tightening torque to follows：
Tightening torque
① 29.4～39.2 N･m {3.0～4.0 kgf･m}
② 29.4～39.2 N･m {3.0～4.0 kgf･m}
③ 29.4～39.2 N･m {3.0～4.0 kgf･m}
④ 35.3 N･m {3.6 kgf･m}
⑤ 35.3 N･m {3.6 kgf･m}
047Y
049Y
048Y
