40
Reassembly (bearing holder, center bearing, thrust washer)
(1) Install the bearing holder with identification cutting mark
at the center and the bearing holder with thrust washer to
the flywheel side, facing the chamfered side frontward.
(2) Install the thrust washer facing the oil groove to the
crankshaft thrust surface.
Bearing holder tightening torque
49.0 – 53.9 N·m
｛5.0 – 5.5 kgf·m｝
(3) Install the metal with oil groove to the upper side and the
one without oil groove to the lower side.
NOTE: Be sure to confirm that the oil holes of the
bearing holder and cylinder block are aligned.
130Y
