27
Disassembly
103Y
Order Disassemble Parts Name
9 Return pipe
10 Injection nozzle・Gasket
11 Oil transfer pipe ･ Eye bolt・Seal washer
12 Connector ・Glow plug
13 Oil pressure switch
14 Thermostat case・Gasket
15 Head cover・O-ring
16 Rocker arm and support bracket assembly ･ O-ring・Cap
NOTE : Remove the caps from each intake valves and exhaust valves.
17 Push rod
18 Cylinder head assembly・Head gasket (discard)
NOTE :
1. Untighten the cylinder head bolts in several steps and remove the cylinder head assembly.
19 Tappet
To Next Page
