67
Unit Part Inspection Items
Standard
Dimension
Standard Value
To be
Repaired
Allowable
Limit
Remarks
Type
(Nozzle) 105007－1170 (NP DN4PDN117)
※BASC.
Injection pressure
MPa {kgf/cm
2
}
14.7{150}
14.2 – 15.2
{145 – 155}
Angle of injection direction
4°
Nozzle and holder tightening
torque
N･ｍ{kgf･m}
58.8－68.6
{6－7}
With cylinder
head installed
Cooling method Forced circulation water cooling
Coolant capacity
(ℓ)
5.0
Reserve
tank 0.6ℓ
Thermostat open temperature
(°C)
82
Thermostat full-open temperature
(°C)
95
V belt (fan) looseness (load at
center 5kg)
5-10
Operation start pressure of
radiator cap negative pressure
valve
kPa{kgf/c ㎡}
73.5
{0.75}
88.2
{0.9}
Operation start pressure of
radiator cap pressure valve
kPa {kgf/c ㎡}
Less than
4.9 {0.05}
Type M001T66081
No. of teeth of pinion gear 11
Shifting method of pinion Magnetic shifting
Wear of commutator diameter
29.4
28.8
Stepped wear of commutator 0.05 0.2
Bending allowance of armature
shaft
0.05
More than
0.08
Length of brush 17.5 9
Spring force of brush
N {kgf}
22.5－32.5
{2.3－3.3}
Less than
8.8 {0.9}
Type A007T03877
12V－40A
Outside diameter of slip ring 22.7 22.1
Length of brush 18.5 5.0
Pulley tightening torque
N⋅m {kgf⋅m}
58.3 – 78.8
{5.95 – 8.05}
※ BASC. is BOSCH AUTOMOTIVE SYSTEM CORPORATION
COOLING SYSTEM
COOLING CONDITIONS
INJECTION NOZZLE
ELECTRICAL SYSTEM
STARTER MOTOR
ALTERNATO
