Siemens SIMADYN D Hardware Manual

Input/output modules
5-10 Hardware - SIMADYN D
Edition 12.2004
EB11
X5,
X6
Significance SU11
at SC55,
cable end
B
Connector
designation when
configuring
1 Binary input 1 1
2 Binary input 2 2
3 Binary input 3 3
4 Binary input 4 4 X5C
5 Binary input 5 5 X6C
6 Binary input 6 6
7 Binary input 7 7
8 Binary input 8 8
9 External 24 V 9
10 External ground 10
11 Binary input 9 11
12 Binary input 10 12
13 Binary input 11 13
14 Binary input 12 14
15 Binary input 13 15 X5D
16 Binary input 14 16 X6D
17 Binary input 15 17
18 Binary input 16 18
19 External 24 V 19
20 External ground 20
Table 5-7 SU11 terminal assignment for SC55, cable end B
SU11 terminal
assignment at
SC55, end B
