Communications support modules
6-26 Hardware - SIMADYN D
Edition 12.2004
6.5.1 Pin assignment
Pin Significance Pin Significance
1 +15 V 21 GND
2 GND 22 GND
3 - 23 -
4 GND 24 -
5 -15 V 25 -
6 Not assigned 26 -
7 Not assigned 27 -T*D
8 Not assigned 28 -
9 Not assigned 29 Not assigned
10 T*D 30 Not assigned
11 NC 31 -Iq2
12 R*D 32 -
13 - 33 -
14 - 34 +T*D
15 -R*D 35 -
16 - 36 -
17 - 37 -Iq1
18 Not assigned 38 +Iq1
19 +Iq2 39 -
20 Not assigned 40 +R*D
Table 6-2 Pin assignment of the SS1 (dual inline, 40 pin)
6.5.2 Technical data
Dimensions (W x H x D) 50.8 x 18.6 x 8.6 mm
Weight 11 g
Data transfer rate Max. 38.4 kbaud
Max. cable length Max. 1000 m
+5 V Max. 95 mA
+15 V Max. 75 mA
-15 V Max. 75 mA
General data
Power supply
