Program memory modules / Interface modules
Hardware - SIMADYN D 8-9
Edition 04.2011
8
8.3.2 Technical data
Mounting system Can be snapped onto mounting rails
Dimensions (W x H x D) 135 x 77 x 59
Weight 0.2 kg
External power supply +24 V DC
Range +20 to +30 V DC
Briefly (t<500 ms) 1,5 x V
rated
Current drain at 24 V 170 mA at the rated output current
Signal level
input +/- 10 V
output +/- 10 V
Input resistance 100 kΩ
Signal level +10 V
Output load resistor >1 kOhm
Zero point error
1)
+ 2 mV
Maximum error +10 mV
Push-pull output 5 mA
Transfer frequency range:
0 to 1 kHz ⏐A/AO⏐ = 0 dB
1 to 3 kHz ⏐A/AO⏐ ε 3 dB
1)
25 °C ambient temperature
8.3.3 Connector assignment
Terminal block -X2 Terminal block -X3
Terminal Designation Terminal Designation
031 Pos. input signal 04 Output signal
032 Neg. input signal 05 Output ground
05 Input ground L+ P24 power supply P
ext
1S Push-pull output 1S Connected with terminal
X2/3S
2S Terminal connected with
X2/05 input ground
2S Connected with terminal
X3/05
3S Connected with X3/1S M M24 power supply M
ext
Table 8-3 Connections of terminal blocks X2 and X3
