Input/output modules
Hardware - SIMADYN D 5-11
Edition 12.2004
5
5.2.2.2 Terminal assignment for SC13
At the particular cable ends, only certain signal types are available, where
only the correct interface modules can be used:
Interface
module
Screw
terminal
(x=1...8)
Significance
SB10
x
5x
1:1 screw terminal
Signal
Reference potential (ground or P24)
SB60
x1
x2
x4
Binary inputs 115/230 V
Ground
Binary input 115 V
Binary input 230 V
SB61
x
1x
5x
Binary inputs 24/48 V
Binary input 24 V
Binary input 48 V
Reference
SB70
x1
x2
x4
Binary outputs (relay)
Common (center contact)
NC contact
NO contact
SB71
x
5x
Binary outputs (transistor)
Signal
Ground
Table 5-8 Terminal assignment, interface module
Terminal
assignment,
interface module
