Program memory modules / Interface modules
8-46 Hardware - SIMADYN D
Edition 04.2011
X1
X2
10 10
11
11
16
16
17
17
23 23
24 24
25
25
1 1
8 8
9
9
PTC
X1
X2
35 35
36
36
43
43
44
44
45 45
46 46
47
47
26 26
33 33
34
34
48 48
49
49
50 50
Fig. 8-20 Circuit diagram, SU13
The components are described in chapter 8.9.1.
8.9.5 Technical data
Dimensions (W x H x D) 45 x 129 x 160 mm
Weight Approx. 0.28 kg
ambient temperature for approbations
for interface modules
The maximum allowable ambient
temperatures of the modules, on which
the interface modules are connected,
are to comply.
SU13
General data
Ambient
temperature
