Subracks
Hardware - SIMADYN D 2-29
Edition 04.2011
2
ï‚· The screens of screen cables must be directly connected to the
grounding- or screen rails and fed to the interface modules, still
screened.
NOTE
dditional information regarding EMC and the ambient conditions, refer
to Section „General technical data“!
2.3.7 Technical data
AC power supply according to DIN IEC 38
Supply voltages
(can be set using the voltage selector switch)
AC 115 V AC 230 V
Input voltage range ±10% ±10%
Input frequency 47-63 Hz 47-63 Hz
Input current 0.8 A 0.4 A
Non-periodic overvoltages acc. to DIN VDE160, A5.3.1.1.2
Voltage 460 V
Duration 1.3 ms
Recovery time, min 0.1 s
Events per hour max. 10
Brief voltage dips acc. to DIN VDE 0160, A5.3.1.1.3
Voltage 0 V
Duration 5 ms
Recovery time, min 0.1 s
Events per hour max. 10
Output voltage 5 V +5.1 V +/- 0.1 V
Output current
3 A
Ripple < 50 mV
ss
Commutating spikes < 5% (of 5V)
Overvoltage protection With suppressor diode,
to protect the modules
Stabilization time < 80 ms after U
in
= 230 V;
<1 ms
after a load step (0.5 ->1)*I
rated
Output voltage +15 V
+15 V +/- 0.3 V
Output current
0 to 0.5 A
Ripple < 150 mV
ss
Input voltages
Output voltages
