Input/output modules
Hardware - SIMADYN D 5-23
Edition 12.2004
5
5.3.3.1 Connector assignment X7 for SC49
IT41
X7
Significance SU 10
at SC49,
cable end
A
Connector
designation when
configuring
1 Binary output 1 1
34 Binary output 2 2
18 Binary output 3 3
2 Binary output 4 4
35 Binary output 5 5 X7A
19 Binary output 6 6
3 Binary output 7 7
36 Binary output 8 8
20 External P24 voltage 9
4 External ground 10
37 Binary output 9 11
21 Binary output 10 12
5 Binary output 11 13
38 Binary output 12 14
22 Binary output 13 15 X7B
6 Binary output 14 16
39 Binary output 15 17
23 Binary output 16 18
7 External P24 voltage 19
40 External ground 20
24 Binary input 1 21
8 Binary input 2 22
41 Binary input 3 23 X7C
25 Binary input 4 24
9 Binary input 5 25
Table 5-18 SU10 terminal assignment for SC49, cable end A
SU10 terminal
assignment at
SC49, end A
