Communications support modules
6-16 Hardware - SIMADYN D
Edition 12.2004
6.3.1 Slave connection
Depending on the master module type, 1 to 8 slaves (CS22) can be
connected:
Master module No. of slots No. of slaves
(CS22)
CS12 1 1
CS13
(consists of CS12 + ICS1)
2 1 to 4
CS14
(consists of CS12 + ICS1 + ICS1)
3 1 to 8
The following diagrams and tables illustrate the fiber-optic cable connections
to be connected for the possible master-slave configurations.
The interfaces are defined (fiber-optic cable connections) by appropriately
configuring in HWConfig.
For CS13 and CS14, the two fiber-optic cable connections on the basic
CS12 module are not used
Master module
CS12
Slave module
CS22
CS12 Type 1
X5 Trans. X6
X6 Rec. X5
Connecting 1 slave
